Recycling

Working with the main world building firms in the sector.
We design and build the following systems:

• Compactors control systems
• Shears control systems
• Single and dual shaft grinders control systems
• Coil Press Binder
• Extractor Centrifuge

Through the use of a dedicated software, we can also dimension the whole fluid power plant, according to the requested machine cycle.

Power: up to 640 kW [860 hp]
Flow rate: up to 6.000 l/min [1590 gpm]
Pressure: up to 420 bar [6000 psi]
Temperature: -40 °C +60 °C [-40 °F +140 °F]
Certifications: according to: SIL, PED requirements
Process Control: WPS, PQR, NDT, mechanical stress and wearing tests
Engineering international standards: UNI EN ISO 13849, ASME, EU Directives rules and specifi cations IEC61508, IEC61511
Painting: based on customer specifications
Surface treatments: galvanization, phosphating, electrolytic protections, nitrocarburizing, stainless steel surface finishing
Materials: steel, cast iron, ergal

Key Components

High-Low Pressure switches
High Flow Cartridge Valves
High Performance Air/Oil Heat Exchangers
Manifold with up to 1m long drilled holes
High Capacity Accumulators

Manifold, HPU (Hydraulic Power Unit) and Integrated System full engineering
Fluid dynamics simulation
Structural calculation
Deep analysis and check of every single system parameter with specific and official report release
Final operational test of the whole system
World Wide commissioning with high level expertise technicians
Rigid and flexible piping and on-site full assistance
40 years-experience in the hydraulic field and a very passionate team of engineers and technicians who work every day close to our customers

Technical Datasheet RECYCLING

Key Components
